Diamana™ WB

The first release in the 6th-generation family.
This shaft delivers a strong, penetrating trajectory and solid swing-through, characteristics expected from a handle-soft design. In addition to the tip materials used in previous generations, the new "New Tip Technology" optimizes torsional control at the tip. The cosmetics have also been updated from the traditional metallic ion plating to a sleek matte finish.

SPEC

Shaft Name	Flex	Length(mm)	Weight(g)	Tip O/D (mm)	Tip Length(mm)	Butt O/D(mm)	Torque(deg)	Kick Pt.
Diamana WB 43	R2	1168	43.0	8.60	75	15.25	5.5	HIGH
Diamana WB 43	R	1168	44.5	8.60	75	15.25	5.4	HIGH
Diamana WB 43	SR	1168	46.0	8.60	75	15.25	5.4	HIGH
Diamana WB 43	S	1168	47.0	8.60	75	15.25	5.3	HIGH
Diamana WB 43	X	1168	48.5	8.60	75	15.25	5.3	HIGH
Diamana WB 53	R	1168	52.0	8.60	75	15.25	4.7	HIGH
Diamana WB 53	SR	1168	53.0	8.60	75	15.25	4.7	HIGH
Diamana WB 53	S	1168	54.0	8.60	75	15.25	4.6	HIGH
Diamana WB 53	X	1168	55.0	8.60	75	15.25	4.6	HIGH
Diamana WB 53	TX	1168	58.0	8.60	75	15.25	4.6	HIGH
Diamana WB 63	R	1168	60.0	8.60	75	15.35	3.2	HIGH
Diamana WB 63	SR	1168	61.0	8.60	75	15.35	3.1	HIGH
Diamana WB 63	S	1168	61.0	8.60	75	15.35	3.1	HIGH
Diamana WB 63	X	1168	63.5	8.60	75	15.35	3.1	HIGH
Diamana WB 63	TX	1168	65.0	8.60	75	15.35	3.0	HIGH
Diamana WB 73	S	1168	70.0	8.60	75	15.35	3.0	HIGH
Diamana WB 73	X	1168	72.0	8.60	75	15.35	2.9	HIGH
Diamana WB 73	TX	1168	73.0	8.60	75	15.35	2.9	HIGH
Diamana WB 83	S	1168	80.0	8.60	75	15.35	2.7	HIGH
Diamana WB 83	X	1168	82.5	8.60	75	15.35	2.7	HIGH
Diamana WB 83	TX	1168	83.5	8.60	75	15.35	2.7	HIGH

[MADE IN CHINA]

TECHNOLOGY

X‑link Tech

A new matrix resin technology that optimizes composition to form a rigid cross‑link structure. Enhances molding properties by up to 14% in strength, 15% in modulus, and 8% in strain-to-failure compared to conventional resins—unlocking MR70’s full potential.
Consistent Feel Design

Minimizes weight differences and butt-diameter variation between flexes in same weight class, and butt diameter differences across 40–80 g specs. Reduces sensory mismatch between weights/flexes, enabling smoother set-up from drivers to fairway woods.
New Tip Technology

Optimizes tip torsion alignment to enhance swing stability from top through downswing for large-head/high‑MOI clubs, delivering efficient energy transmission during impact.

MATERIAL

DIALEAD™

Lightweight, high-modulus pitch‑based carbon fiber used in aerospace; its low thermal expansion ensures dimensional stability for superior reinforcement effect.
