TENSEI™ Pro Orange 1K
The Pro Orange 1K series builds upon the 2019 CK Pro Orange by further reinforcing the tip section, reducing vertical dispersion caused by toe-down at impact. Additionally, by lowering the torque, it minimizes side-to-side launch deviations and reduces side spin—evolving into a shaft that resists curvature. While retaining the easy-to-swing counterbalance design, it maximizes the potential of carbon fiber.
SPEC
| Shaft Name | Flex | Length(mm) | Weight(g) | Tip O/D (mm) | Tip Length(mm) | Butt O/D(mm) | Torque(deg) | Kick Pt. |
|---|---|---|---|---|---|---|---|---|
| TENSEI™ Pro Orange 1K 50 | R | 1168 | 55.5 | 8.6 | 75 | 15.20 | 3.9 | HIGH |
| TENSEI™ Pro Orange 1K 50 | S | 1168 | 57 | 8.6 | 75 | 15.30 | 3.9 | HIGH |
| TENSEI™ Pro Orange 1K 50 | X | 1168 | 60.5 | 8.6 | 75 | 15.35 | 3.8 | HIGH |
| TENSEI™ Pro Orange 1K 50 | TX | 1168 | 61.5 | 8.6 | 75 | 15.35 | 3.8 | HIGH |
| TENSEI™ Pro Orange 1K 60 | R | 1168 | 68 | 8.6 | 75 | 15.35 | 3.0 | HIGH |
| TENSEI™ Pro Orange 1K 60 | S | 1168 | 69 | 8.6 | 75 | 15.35 | 3.0 | HIGH |
| TENSEI™ Pro Orange 1K 60 | X | 1168 | 72.5 | 8.6 | 75 | 15.50 | 3.0 | HIGH |
| TENSEI™ Pro Orange 1K 60 | TX | 1168 | 72.5 | 8.6 | 75 | 15.50 | 3.0 | HIGH |
| TENSEI™ Pro Orange 1K 70 | S | 1168 | 78.5 | 8.6 | 75 | 15.40 | 2.7 | HIGH |
| TENSEI™ Pro Orange 1K 70 | X | 1168 | 81.5 | 8.6 | 75 | 15.50 | 2.7 | HIGH |
| TENSEI™ Pro Orange 1K 70 | TX | 1168 | 82 | 8.6 | 75 | 15.50 | 2.7 | HIGH |
| TENSEI™ Pro Orange 1K 80 | S | 1168 | 86 | 8.6 | 75 | 15.35 | 2.5 | HIGH |
| TENSEI™ Pro Orange 1K 80 | X | 1168 | 89 | 8.6 | 75 | 15.40 | 2.4 | HIGH |
| TENSEI™ Pro Orange 1K 80 | TX | 1168 | 90 | 8.6 | 75 | 15.40 | 2.4 | HIGH |
TECHNOLOGY
-
X‑link Tech
A new matrix resin technology that optimizes composition to form a rigid cross‑link structure. Enhances molding properties by up to 14% in strength, 15% in modulus, and 8% in strain-to-failure compared to conventional resins—unlocking MR70’s full potential.
MATERIAL
-
MR70™
A breakthrough carbon fiber balancing stiffness and strength by reengineering precursor and resin processes. Offers ~20% higher strength and ~10% higher modulus vs. previous grades.
-
1K Weave
Fabric built from single-filament bundles (1K) providing dense, flexible weaving. Offers high formability, precision in modeling, reduced creep, and efficient reinforcement with minimal resin usage.
-
Tungsten Prepreg
High‑density tungsten‑loaded prepreg enables optimal weight distribution, delivering smooth stability through finish without stress.
